Modified PP
欄目：modified engineering plastics 發布時間：2021-05-31 09:33
Environment-friendly flame-retardant; and good heat resistance, stable size, high mechanical strength and good appearance...
 Modified PP |
|||||
|
Applications：Home appliance and communication equipment, building materials, auto parts, and chemical equipment injection molding parts Modified Features: Reinforced, flame retardant Product Features: Environment-friendly flame-retardant; and good heat resistance, stable size, high mechanical strength and good appearance |
|||||
| 測試項目與標準Test Items & Standards |
增強型號 Reinforced |
阻燃型號 Flame Retardant |
|||
| 項目Items | 測試標準Standard | 測試條件 Test Condition | 國際單位S.I. Units | PP-30GF | FRPP-V0 |
| 機械性能 Mechanical Properties | |||||
| 拉伸強度Tensile Strength | ASTM D638 | 10mm/min | MPa | 75 | 25 |
| 伸長率 Elongation | ASTM D638 | 10mm/min | % | 3.5 | 30 |
| 彎曲強度 Flexural Strength | ASTM D790 | 2mm/min | MPa | 90 | 35 |
| 彎曲模量Flexural Modulus | ASTM D790 | 2mm/min | MPa | 5000 | 2000 |
|
懸臂梁缺口沖擊強度 Impact Strength, Izod notched |
ASTM D256 | 3.2mm,23℃ | J/m | 100 | 50 |
| 洛氏硬度 Rockwell Hardness | ASTM D785 | R-Scale | - | 105 | 80 |
| 熱性能 Thermal Properties | |||||
|
熱變形溫度 Heat Distortion Temp |
ASTM D648 | 0.45MPa,6.4mm | ℃ | 160 | 125 |
| 1.8MPa,6.4mm | 150 | CLass | |||
| 電性能 Electrical Properties | |||||
| 體積電阻率Volume Resistivity | ASTM D257 | - | Ω.cm | 1016 | |
| 其他 Others | |||||
| 玻纖含量Glass Fiber | -- | -- | % | 30 | |
| 比重Specific Gravity | ASTM D792 | 23℃ | g/cm3 | 1.14 | 1.26 |
| 收縮率Mold Shrinkage | ASTM D955 | 23℃ | % | 0.3/1.0 | 1.0/1.2 |
| 吸水率Weather Resistant | ASTM D570 | 23℃，24h | % | 0.02 | |
| 阻燃性Flammability | UL94 | 1.6mm | class | HB | V0 |
| 3.2mm | HB | V0 | |||
| 建議加工工藝 Suggesting processing technology | |||||
| 熔體溫度Melt Temp | ℃ | 220-245 | 220-240 | ||
| 料筒溫度Barrel Zone Temp | ℃ | 180-230 | 180-220 | ||
| 模具溫度Mold Temp | ℃ | 30-60 | 30-60 | ||
| 預干燥Pre-Dry Requirements | 80-90℃ 2hr | 100℃ 4-6hr | |||
| 注：以上數值是根據實驗室標準測定的代表數值，僅供客戶參考，不作為質保承諾。 | |||||
| Note: The above data is based on standard laboratory condition, for reference only, not for product warranty. | |||||
